chic c-line Fiat Ducato T 4.9 LE

Quick overview
Length
7340 mm
Tech. permissible laden weight
4250 kg
Max. tech. permissible laden weight
4500 kg
Max. Sleeping locations
3
Price
₤ 105.110,–
Special features
  • L-shaped lounge seating area with wide side seat bench and rectangular living area table with chrome piping
  • Swivel-out shoe cabinet with holding system for up to 4 pairs of shoes integrated in plinth of seat bench
  • Raised kitchen worktop with designer bar cabinet as visual room divider and additional work surface
  • Large luxury corner kitchen with curved worktop, slide-out storage cabinet integrated in round washroom wall
  • Luxury washroom with separate shower
  • Changing room separable via luxury washroom door with 3-way function thanks to washroom double door and solid wooden sliding doors
  • Large lengthways single beds with pull-out comfort access steps and wardrobes below with out-standing interior height thanks to lowering into double floor
  • Designer shelves in sleeping area, TV cabinet with special TV pull-out system (optional)
  • Exclusive lighting concept in LED light technology with dimming function, main light with numer-ous spotlights and indirect ambient light, separately controllable
Technical data
Standard chassis Fiat Ducato AL-KO low frame 40 heavy
Basic motorisation Diesel 2,2 l (140 PS/103 kW)
Total length 7340 mm
Total width 2270 mm
Total height 2890 mm
Wheelbase 4143 mm
Double floor height / double floor storage compart- ment 220/460 mm
Standing height in living area 1980 mm
Rear garage interior height 1200 mm
Door width/height rear garage passengers side 1050/1140 mm
Door width/height rear garage drivers side 1050/1140 mm
Tech. permissible total weight 4250 kg
Max. tech. permissible laden weight 4500 kg
Weight in running order | Legal tolerance of -/+ 5% 3.315 (3.149 - 3.481) kg
Weight of additional equipment in series production specified by the manufacturer 581 kg
Max. towed load 1800 kg
Sitting places (standard/optional) 4
Sleeping places 2
Sleeping places max. 3
Type of sleeping places Single bed
Rear bed dimensions 2000/1900 x 850
230 V / 12 V / USB sockets 4 / 1 /2
Seating area bed conversion dimensions (mm) * 1920 x 1125 / 670
Fridge volume / of which freezer compartment (l) 153/29 l
Fresh water tank volume with filling in running order (l) 20 l
Heating system Truma Combi 6
Fresh water volume 170 l
Waste water volume 140 l
Battery capacity 2x80 Ah Gel
Price from ₤ 105.110,–
