chic c-line Fiat Ducato I 5.0 QB L

Quick overview
Length
7780 mm
Tech. permissible laden weight
4250 kg
Max. tech. permissible laden weight
4500 (*) kg
Max. Sleeping locations
5
Price
₤ 126.850,–
Special features
  • L-shaped lounge seating area with wide side seat bench and rectangular living area table with chrome piping
  • Pull-out shoe cabinet with holding system for up to four pairs of shoes integrated in plinth of seat bench
  • Raised kitchen worktop with designer bar cabinet as visual room divider and additional work surface
  • Large luxury corner kitchen with curved worktop, slide-out storage cabinet integrated in round washroom wall
  • Luxury washroom with separate shower
  • Changing room separable via luxury washroom door with 3-way function thanks to washroom double door and pull out TV wall and room divider
  • Floor-to-ceiling wardrobe
  • Large queen-size bed with convenient access, comfortable sleeping width up to foot area, two wardrobes at side of bed, two large drawers at front of bed
  • Exclusive lighting concept in LED light technology with dimming function, main light with numerous spotlights and indirect ambient light, separately controllable
Technical data
Standard chassis Fiat Ducato AL-KO low frame 40 heavy
Basic motorisation Diesel 2,2 l (180 PS/132 kW)
Total length 7780 mm
Total width 2270 mm
Total height 2890 mm
Wheelbase 4343 mm
Double floor height / double floor storage compart- ment 220/460 mm
Standing height in living area 1980 mm
Rear garage interior height 1120/1240* mm
Door width/height rear garage passengers side 1050/1100 mm
Door width/height rear garage drivers side 1050/1100 mm
Tech. permissible total weight 4250 kg
Max. tech. permissible laden weight 4500 (*) kg
Weight in running order | Legal tolerance of -/+ 5% 3.485 (3.311 - 3.659) kg
Weight of additional equipment in series production specified by the manufacturer 405 kg
Max. towed load 1800 kg
Sitting places (standard/optional) 4 | 5
Sleeping places 4
Sleeping places max. 5
Type of sleeping places Queen-size bed
Rear bed dimensions 1950 x 1450
230 V / 12 V / USB sockets 5 / 2 /2
Seating area bed conversion dimensions (mm) * 1920 x 1125 / 670**
Fridge volume / of which freezer compartment (l) 153/29 l
Fresh water tank volume with filling in running order (l) 20 l
Folding bed dimensions 1950 x 1600
Heating system Truma Combi 6
Fresh water volume 170 l
Waste water volume 140 l
Battery capacity 2x80 Ah Gel
Price from ₤ 126.850,–
(*) Option with max. payload *Optional Pedelec scooter garage **in conjunction with special equipment
