chic c-line Fiat Ducato T 5.0 QB

Find model Trading partners
Quick overview
Length
7430 mm
tech. permissible gross vehicle weight
4250 kg
Max. tech. permissible gross vehicle weight
4500 (*) kg
Max. Sleeping locations
3
Price
₤ 111.790,–
Special features
  • L-shaped lounge seating area with wide side seat bench and rectangular living area table with chrome piping
  • Pull-out shoe cabinet with holding system for up to four pairs of shoes integrated in plinth of seat bench
  • Raised kitchen worktop with designer bar cabinet as visual room divider and additional work surface
  • Large luxury corner kitchen with curved worktop, slide-out storage cabinet integrated in round washroom wall
  • Luxury washroom with separate shower
  • Changing room separable via luxury washroom door with 3-way function thanks to washroom double door and pull out TV wall and room divider
  • Large queen-size bed with convenient access, comfortable sleeping width up to the foot area, two wardrobes at side of bed, two large drawers at front of bed
  • Exclusive lighting concept in LED light technology with dimming function, main light with numerous spotlights and indirect ambient light, separately controllable
Technical data
Standard chassis Fiat Ducato AL-KO low frame 40 heavy
Base engine Diesel 2,2 l (180 HP/132 kW)
Total length 7430 mm
Total width 2270*** mm
Total height 2920 mm
Wheel base 4143 mm
Double floor height / double floor storage compartment 220/460 mm
Headroom in living area 1980 mm
Rear garage interior height 1120/1240* mm
Door width/height rear garage passengers side 1050 x 1100 mm
Door width/height rear garage drivers side 1050 x 1100 mm
Technically permissible gross vehicle weight 4250 kg
Max. Technically permissible gross vehicle weight 4500 (*) kg
Weight in running order | Legal tolerance of -/+ 5% 3.365 (3.197-3.533) kg
Max. weight of additional equipment in series production specified by the manufacturer 507 kg
Max. towed load 1800 kg
Max. number of seats with 3-point safety belt as standard while driving (standard / optional) 4
Sleeping berths 2 | 3
Max. Sleeping berth 3
Type of sleeping places Queen-size bed
Rear bed dimensions 1950 x 1450
230 V / 12 V / USB sockets 4 / 1 / 2
Seating area bed conversion dimensions (mm) * 1920 x 1125 / 670**
Fridge volume / of which freezer compartment (l) 153 / 29 l
Fresh water tank volume with filling in running order (l) 20 l
Heating system Truma Combi 6
Fresh water volume 170 l
Waste water volume 140 l
Battery capacity 2x80 Ah Gel
List price including 20% VAT (₤) and registration documents ₤ 111.790,–
https://configurator.carthago.com/customer/catalog?language=en&modelYear=2025&model=chic%20c-line%20T%20Fiat&layout=C-line%20T%205.0%20QB&priceList=gb
(*) Optional with max. payload *Optional Pedelec scooter garage ** In conjunction with special equipment ***Total vehicle width is the measurement from exterior wall to exterior wall (wheel arches on the side, approx.: + 70 mm)
